Cod: 1.02.0350.00TTT - Nombre: SAE J1939 CAN Driver

IXXAT

SAE J1939 CAN Driver

Software package for connection of the
J1939 protocol software to the target hardware

The SAE J1939 CAN driver provides all necessary functions for connection of the J1939 protocol software to the target hardware and sup

Características destacadas

    undefined

Software package for connection of the
J1939 protocol software to the target hardware

The SAE J1939 CAN driver provides all necessary functions for connection of the J1939 protocol software to the target hardware and supports both the single and the multi-channel version of the protocol software.

The CAN driver is extended with modules for abstracting the operating system (if available) and the CPU and therefore enables simple commissioning of the J1939 protocol software without further adaptation. The required resources of the target hardware are a free timer interrupt for time monitoring of the protocol and an interrupt of the CAN controller. In addition to the generic version for the IXXAT PC/CAN interfaces, further portings are available.

A complete overview of all supported CPUs/CAN controllers can be found on the following page:

Supported CPUs/CAN controllers

Based on the generic version, porting of the CAN driver is also easily possible for the customer thanks to the documentation provided. If required, IXXAT will carry out appropriate adaptations of the J1939 CAN driver on behalf of the customer.


SAE J1939 Stack CAN Driver


Contents of delivery

  • SAE J1939 CAN driver as source code
  • Target license (restricted to the target platform)
  • Quick Start Guide
  • Sample programs in C
  • Technical support


Further services

(not included in contents of delivery)

  • Maintenance contract
    HMS offers a maintenance contract to supplement the J1939 software package. The maintenance contract includes the following services during the contractual period:
    - Free updates and troubleshooting
    - Technical support


Order number

1.02.0350.00TTT SAE J1939 CAN Driver (target options on request)
