IXXAT

Código: 1.01.0047.33220

Active PCI board

1-2 x CAN (High-/Low-Speed)

The iPC-I XC16/PCI is an active CAN PCI interface for 5 V and 3.3 V PCI bus systems with optional Low-Speed bus interface. The on-board microcontroller offers filtering, prep

  • Active CAN board with 16 bit microcontroller
  • Common driver interface for easy exchange of the PC interface type
  • Features filtering, preprocessing, time stamped storage of CAN messages
  • High-/Low-Speed bus interface optional
  • Galvanic isolation optional
PC bus interface PCI-Bus (V2.2), 32 Bit / 33 MHz, 5 Volt or 3.3 Volt
PC address range Plug & Play, 16 kB memory mapped and 128 bytes I/O area
Interrupts INT A, Plug & Play
Microcontroller Infineon XC161
CAN controller TwinCAN (two CAN channels); CAN 2.0 A/B
CAN bus interface ISO 11898-2 according to CiA 303-1, Sub D9 connector, optional high-/low-speed bus interface (ISO 11898-3) switchable via software
Power supply 5 V DC, 100 mA typ.; 3.3 V DC, 185 mA typ.
Galvanic isolation optional (1 kV, 1 sec.)
Temperature range -20 ºC ... +70 ºC
Certification CE, CSA/UL, FCC, EN 60601-1
Size Approx. 123 x 90 mm

iPC-I XC16/PCI

IXXAT

Código: 1.01.0047.33260

Active PCI board

1-2 x CAN (High-/Low-Speed)

The iPC-I XC16/PCI is an active CAN PCI interface for 5 V and 3.3 V PCI bus systems with optional Low-Speed bus interface. The on-board microcontroller offers filtering, prep

  • Active CAN board with 16 bit microcontroller
  • Common driver interface for easy exchange of the PC interface type
  • Features filtering, preprocessing, time stamped storage of CAN messages
  • High-/Low-Speed bus interface optional
  • Galvanic isolation optional
PC bus interface PCI-Bus (V2.2), 32 Bit / 33 MHz, 5 Volt or 3.3 Volt
PC address range Plug & Play, 16 kB memory mapped and 128 bytes I/O area
Interrupts INT A, Plug & Play
Microcontroller Infineon XC161
CAN controller TwinCAN (two CAN channels); CAN 2.0 A/B
CAN bus interface ISO 11898-2 according to CiA 303-1, Sub D9 connector, optional high-/low-speed bus interface (ISO 11898-3) switchable via software
Power supply 5 V DC, 100 mA typ.; 3.3 V DC, 185 mA typ.
Galvanic isolation optional (1 kV, 1 sec.)
Temperature range -20 ºC ... +70 ºC
Certification CE, CSA/UL, FCC, EN 60601-1
Size Approx. 123 x 90 mm

iPC-I XC16/PCI

IXXAT

Código: 1.01.0320.20110

Versatile industrial Ethernet PC interface with multi-protocol support

IXXAT INpact allows you to connect a PC to any industrial network. It combines proven Anybus technology with years of IXXAT know-how in the area of PC int

  • One board for all common industrial Ethernet networks
  • Easy switching between protocols through a standardized API
  • Fast time to market, with minimal development efforts required
  • Easy integration thanks to different form factors
  • High performance for demanding real-time applications
  • Future-proof solution based on proved IXXAT and Anybus technologies
 INpact CE Slave PCIe Standard/Low Profile INpact CE Slave PCIe Mini
Field bus interface Two Ethernet ports, 100/10 Mbit Two Ethernet ports, 100/10 Mbit
PC interfaces PCI Express single lane port (x1) according to PCI Express base specification, revision 1.1 Mini PCI Express (x1)
Network handling Anybus NP40 Anybus NP40
Power supply Via PCIe socket (3.3 V / 12 V DC) Via PCIe (3.3 V)
Current consumption Typ. 270 mA / 3.3 V DC, 110 mA / 12 V DC Typ. 600 mA / 3.3 V DC
Form factor Standard height / low profile PCI Express add-in card profile Full Mini Card form factor
Operating temperature range 0 °C to 70 °C Option: -40 °C to 70° C -40 °C to 60 °C
Dimensions  64 x 105 mm  30 x 50.95 x 12 mm (with cable)
Weight approx. 52 g approx. 26 g (board, cable, bus interface)

INpact CE Slave PCIe

IXXAT

Código: 1.01.0320.20120

Versatile industrial Ethernet PC interface with multi-protocol support

IXXAT INpact allows you to connect a PC to any industrial network. It combines proven Anybus technology with years of IXXAT know-how in the area of PC int

  • One board for all common industrial Ethernet networks
  • Easy switching between protocols through a standardized API
  • Fast time to market, with minimal development efforts required
  • Easy integration thanks to different form factors
  • High performance for demanding real-time applications
  • Future-proof solution based on proved IXXAT and Anybus technologies
 INpact CE Slave PCIe Standard/Low Profile INpact CE Slave PCIe Mini
Field bus interface Two Ethernet ports, 100/10 Mbit Two Ethernet ports, 100/10 Mbit
PC interfaces PCI Express single lane port (x1) according to PCI Express base specification, revision 1.1 Mini PCI Express (x1)
Network handling Anybus NP40 Anybus NP40
Power supply Via PCIe socket (3.3 V / 12 V DC) Via PCIe (3.3 V)
Current consumption Typ. 270 mA / 3.3 V DC, 110 mA / 12 V DC Typ. 600 mA / 3.3 V DC
Form factor Standard height / low profile PCI Express add-in card profile Full Mini Card form factor
Operating temperature range 0 °C to 70 °C Option: -40 °C to 70° C -40 °C to 60 °C
Dimensions  64 x 105 mm  30 x 50.95 x 12 mm (with cable)
Weight approx. 52 g approx. 26 g (board, cable, bus interface)

INpact CE Slave PCIe

IXXAT

Código: 1.01.0340.20101

Versatile industrial Ethernet PC interface with multi-protocol support

IXXAT INpact allows you to connect a PC to any industrial network. It combines proven Anybus technology with years of IXXAT know-how in the area of PC int

  • One board for all common industrial Ethernet networks
  • Easy switching between protocols through a standardized API
  • Fast time to market, with minimal development efforts required
  • Easy integration thanks to different form factors
  • High performance for demanding real-time applications
  • Future-proof solution based on proved IXXAT and Anybus technologies
 INpact CE Slave PCIe Standard/Low Profile INpact CE Slave PCIe Mini
Field bus interface Two Ethernet ports, 100/10 Mbit Two Ethernet ports, 100/10 Mbit
PC interfaces PCI Express single lane port (x1) according to PCI Express base specification, revision 1.1 Mini PCI Express (x1)
Network handling Anybus NP40 Anybus NP40
Power supply Via PCIe socket (3.3 V / 12 V DC) Via PCIe (3.3 V)
Current consumption Typ. 270 mA / 3.3 V DC, 110 mA / 12 V DC Typ. 600 mA / 3.3 V DC
Form factor Standard height / low profile PCI Express add-in card profile Full Mini Card form factor
Operating temperature range 0 °C to 70 °C Option: -40 °C to 70° C -40 °C to 60 °C
Dimensions  64 x 105 mm  30 x 50.95 x 12 mm (with cable)
Weight approx. 52 g approx. 26 g (board, cable, bus interface)

INpact CE Slave PCIe

IXXAT

Código: 1.01.0320.24110

Versatile industrial Ethernet PC interface for Profinet IRT

The dedicated Profinet IRT version of the IXXAT INpact comes with a pre-installed network protocol. It enables the easy connection of PC-based Profin

    undefined
 INpact CE Slave PCIe Standard/Low Profile INpact CE Slave PCIe Mini
Field bus interface Two Ethernet ports, 100/10 Mbit Two Ethernet ports, 100/10 Mbit
PC interfaces PCI Express single lane port (x1) according to PCI Express base specification, revision 1.1 Mini PCI Express (x1)
Network handling Anybus NP40 Anybus NP40
Power supply Via PCIe socket (3.3 V / 12 V DC) Via PCIe (3.3 V)
Current consumption Typ. 270 mA / 3.3 V DC, 110 mA / 12 V DC Typ. 600 mA / 3.3 V DC
Form factor Standard height / low profile PCI Express add-in card profile Full Mini Card form factor
Operating temperature range 0 °C to 70 °C Option: -40 °C to 70° C -40 °C to 60 °C
Dimensions  64 x 105 mm  30 x 50.95 x 12 mm (with cable)
Weight approx. 52 g approx. 26 g (board, cable, bus interface)

INpact PIR Slave PCIe

IXXAT

Código: 1.01.0320.24120

Versatile industrial Ethernet PC interface for Profinet IRT

The dedicated Profinet IRT version of the IXXAT INpact comes with a pre-installed network protocol. It enables the easy connection of PC-based Profin

    undefined
 INpact CE Slave PCIe Standard/Low Profile INpact CE Slave PCIe Mini
Field bus interface Two Ethernet ports, 100/10 Mbit Two Ethernet ports, 100/10 Mbit
PC interfaces PCI Express single lane port (x1) according to PCI Express base specification, revision 1.1 Mini PCI Express (x1)
Network handling Anybus NP40 Anybus NP40
Power supply Via PCIe socket (3.3 V / 12 V DC) Via PCIe (3.3 V)
Current consumption Typ. 270 mA / 3.3 V DC, 110 mA / 12 V DC Typ. 600 mA / 3.3 V DC
Form factor Standard height / low profile PCI Express add-in card profile Full Mini Card form factor
Operating temperature range 0 °C to 70 °C Option: -40 °C to 70° C -40 °C to 60 °C
Dimensions  64 x 105 mm  30 x 50.95 x 12 mm (with cable)
Weight approx. 52 g approx. 26 g (board, cable, bus interface)

INpact PIR Slave PCIe

IXXAT

Código: 1.01.0340.24101

Versatile industrial Ethernet PC interface for Profinet IRT

The dedicated Profinet IRT version of the IXXAT INpact comes with a pre-installed network protocol. It enables the easy connection of PC-based Profin

    undefined
 INpact CE Slave PCIe Standard/Low Profile INpact CE Slave PCIe Mini
Field bus interface Two Ethernet ports, 100/10 Mbit Two Ethernet ports, 100/10 Mbit
PC interfaces PCI Express single lane port (x1) according to PCI Express base specification, revision 1.1 Mini PCI Express (x1)
Network handling Anybus NP40 Anybus NP40
Power supply Via PCIe socket (3.3 V / 12 V DC) Via PCIe (3.3 V)
Current consumption Typ. 270 mA / 3.3 V DC, 110 mA / 12 V DC Typ. 600 mA / 3.3 V DC
Form factor Standard height / low profile PCI Express add-in card profile Full Mini Card form factor
Operating temperature range 0 °C to 70 °C Option: -40 °C to 70° C -40 °C to 60 °C
Dimensions  64 x 105 mm  30 x 50.95 x 12 mm (with cable)
Weight approx. 52 g approx. 26 g (board, cable, bus interface)

INpact PIR Slave PCIe

IXXAT

Código: 1.01.0320.21110

Versatile industrial Ethernet PC interface for EtherCAT

The dedicated EtherCAT version of the IXXAT INpact comes with a pre-installed network protocol. It enables the easy connection of PC-based EtherCAT Slave

    undefined
 INpact CE Slave PCIe Standard/Low Profile INpact CE Slave PCIe Mini
Field bus interface Two Ethernet ports, 100/10 Mbit Two Ethernet ports, 100/10 Mbit
PC interfaces PCI Express single lane port (x1) according to PCI Express base specification, revision 1.1 Mini PCI Express (x1)
Network handling Anybus NP40 Anybus NP40
Power supply Via PCIe socket (3.3 V / 12 V DC) Via PCIe (3.3 V)
Current consumption Typ. 270 mA / 3.3 V DC, 110 mA / 12 V DC Typ. 600 mA / 3.3 V DC
Form factor Standard height / low profile PCI Express add-in card profile Full Mini Card form factor
Operating temperature range 0 °C to 70 °C Option: -40 °C to 70° C -40 °C to 60 °C
Dimensions  64 x 105 mm  30 x 50.95 x 12 mm (with cable)
Weight approx. 52 g approx. 26 g (board, cable, bus interface)

INpact ECT Slave PCIe

IXXAT

Código: 1.01.0320.21120

Versatile industrial Ethernet PC interface for EtherCAT

The dedicated EtherCAT version of the IXXAT INpact comes with a pre-installed network protocol. It enables the easy connection of PC-based EtherCAT Slave

    undefined
 INpact CE Slave PCIe Standard/Low Profile INpact CE Slave PCIe Mini
Field bus interface Two Ethernet ports, 100/10 Mbit Two Ethernet ports, 100/10 Mbit
PC interfaces PCI Express single lane port (x1) according to PCI Express base specification, revision 1.1 Mini PCI Express (x1)
Network handling Anybus NP40 Anybus NP40
Power supply Via PCIe socket (3.3 V / 12 V DC) Via PCIe (3.3 V)
Current consumption Typ. 270 mA / 3.3 V DC, 110 mA / 12 V DC Typ. 600 mA / 3.3 V DC
Form factor Standard height / low profile PCI Express add-in card profile Full Mini Card form factor
Operating temperature range 0 °C to 70 °C Option: -40 °C to 70° C -40 °C to 60 °C
Dimensions  64 x 105 mm  30 x 50.95 x 12 mm (with cable)
Weight approx. 52 g approx. 26 g (board, cable, bus interface)

INpact ECT Slave PCIe

IXXAT

Código: 1.01.0340.21101

Versatile industrial Ethernet PC interface for EtherCAT

The dedicated EtherCAT version of the IXXAT INpact comes with a pre-installed network protocol. It enables the easy connection of PC-based EtherCAT Slave

    undefined
 INpact CE Slave PCIe Standard/Low Profile INpact CE Slave PCIe Mini
Field bus interface Two Ethernet ports, 100/10 Mbit Two Ethernet ports, 100/10 Mbit
PC interfaces PCI Express single lane port (x1) according to PCI Express base specification, revision 1.1 Mini PCI Express (x1)
Network handling Anybus NP40 Anybus NP40
Power supply Via PCIe socket (3.3 V / 12 V DC) Via PCIe (3.3 V)
Current consumption Typ. 270 mA / 3.3 V DC, 110 mA / 12 V DC Typ. 600 mA / 3.3 V DC
Form factor Standard height / low profile PCI Express add-in card profile Full Mini Card form factor
Operating temperature range 0 °C to 70 °C Option: -40 °C to 70° C -40 °C to 60 °C
Dimensions  64 x 105 mm  30 x 50.95 x 12 mm (with cable)
Weight approx. 52 g approx. 26 g (board, cable, bus interface)

INpact ECT Slave PCIe

IXXAT

Código: 1.01.0320.22110

Versatile industrial Ethernet PC interface for EtherNet/IP

The dedicated EtherNet/IP version of the IXXAT INpact comes with a pre-installed network protocol. It enables the easy connection of PC-based EtherNet/

    undefined
 INpact CE Slave PCIe Standard/Low Profile INpact CE Slave PCIe Mini
Field bus interface Two Ethernet ports, 100/10 Mbit Two Ethernet ports, 100/10 Mbit
PC interfaces PCI Express single lane port (x1) according to PCI Express base specification, revision 1.1 Mini PCI Express (x1)
Network handling Anybus NP40 Anybus NP40
Power supply Via PCIe socket (3.3 V / 12 V DC) Via PCIe (3.3 V)
Current consumption Typ. 270 mA / 3.3 V DC, 110 mA / 12 V DC Typ. 600 mA / 3.3 V DC
Form factor Standard height / low profile PCI Express add-in card profile Full Mini Card form factor
Operating temperature range 0 °C to 70 °C Option: -40 °C to 70° C -40 °C to 60 °C
Dimensions  64 x 105 mm  30 x 50.95 x 12 mm (with cable)
Weight approx. 52 g approx. 26 g (board, cable, bus interface)

INpact EIP Slave PCIe

IXXAT

Código: 1.01.0320.22120

Versatile industrial Ethernet PC interface for EtherNet/IP

The dedicated EtherNet/IP version of the IXXAT INpact comes with a pre-installed network protocol. It enables the easy connection of PC-based EtherNet/

    undefined
 INpact CE Slave PCIe Standard/Low Profile INpact CE Slave PCIe Mini
Field bus interface Two Ethernet ports, 100/10 Mbit Two Ethernet ports, 100/10 Mbit
PC interfaces PCI Express single lane port (x1) according to PCI Express base specification, revision 1.1 Mini PCI Express (x1)
Network handling Anybus NP40 Anybus NP40
Power supply Via PCIe socket (3.3 V / 12 V DC) Via PCIe (3.3 V)
Current consumption Typ. 270 mA / 3.3 V DC, 110 mA / 12 V DC Typ. 600 mA / 3.3 V DC
Form factor Standard height / low profile PCI Express add-in card profile Full Mini Card form factor
Operating temperature range 0 °C to 70 °C Option: -40 °C to 70° C -40 °C to 60 °C
Dimensions  64 x 105 mm  30 x 50.95 x 12 mm (with cable)
Weight approx. 52 g approx. 26 g (board, cable, bus interface)

INpact EIP Slave PCIe

IXXAT

Código: 1.01.0340.22101

Versatile industrial Ethernet PC interface for EtherNet/IP

The dedicated EtherNet/IP version of the IXXAT INpact comes with a pre-installed network protocol. It enables the easy connection of PC-based EtherNet/

    undefined
 INpact CE Slave PCIe Standard/Low Profile INpact CE Slave PCIe Mini
Field bus interface Two Ethernet ports, 100/10 Mbit Two Ethernet ports, 100/10 Mbit
PC interfaces PCI Express single lane port (x1) according to PCI Express base specification, revision 1.1 Mini PCI Express (x1)
Network handling Anybus NP40 Anybus NP40
Power supply Via PCIe socket (3.3 V / 12 V DC) Via PCIe (3.3 V)
Current consumption Typ. 270 mA / 3.3 V DC, 110 mA / 12 V DC Typ. 600 mA / 3.3 V DC
Form factor Standard height / low profile PCI Express add-in card profile Full Mini Card form factor
Operating temperature range 0 °C to 70 °C Option: -40 °C to 70° C -40 °C to 60 °C
Dimensions  64 x 105 mm  30 x 50.95 x 12 mm (with cable)
Weight approx. 52 g approx. 26 g (board, cable, bus interface)

INpact EIP Slave PCIe

IXXAT

Código: 1.01.0320.25110

Versatile industrial Ethernet PC interface for Powerlink

The dedicated Powerlink version of the IXXAT INpact comes with a pre-installed network protocol. It enables the easy connection of PC-based Powerlink Sl

    undefined
 INpact CE Slave PCIe Standard/Low Profile INpact CE Slave PCIe Mini
Field bus interface Two Ethernet ports, 100/10 Mbit Two Ethernet ports, 100/10 Mbit
PC interfaces PCI Express single lane port (x1) according to PCI Express base specification, revision 1.1 Mini PCI Express (x1)
Network handling Anybus NP40 Anybus NP40
Power supply Via PCIe socket (3.3 V / 12 V DC) Via PCIe (3.3 V)
Current consumption Typ. 270 mA / 3.3 V DC, 110 mA / 12 V DC Typ. 600 mA / 3.3 V DC
Form factor Standard height / low profile PCI Express add-in card profile Full Mini Card form factor
Operating temperature range 0 °C to 70 °C Option: -40 °C to 70° C -40 °C to 60 °C
Dimensions  64 x 105 mm  30 x 50.95 x 12 mm (with cable)
Weight approx. 52 g approx. 26 g (board, cable, bus interface)

INpact EPL Slave PCIe

Actualmente estamos trabajando en mostrarte los mejores resultados, si no encuentras el producto que buscas contacta con nosotros a través de info@er-soft.com o al número Tel. +34 916-408-408
Bienvenido a ER-Soft.
ER-Soft con la ley orgánica de protección de datos
Política de cookies.
Utilizamos cookies propias y de terceros para mejorar nuestros servicios y mostrarle publicidad relacionada con sus preferencias mediante el análisis de sus hábitos de navegación.
Si continúa navegando, consideramos que acepta su uso.
Más información pulsando aquí
X

¿Necesitas ayuda? Click

ayuda ER-Soft
X
Consulta a ER-Soft. *



*



* *Campos obligatorios.




*Al enviar el formulario consideramos que esta de acuerdo, con nuestra política de datos. Ver política de datos
X
