IXXAT

Código: 1.01.0070.10200

Passive PC/104 board

1-2 x CAN (High-Speed)

The PC-I 04/104 represents a low-priced solution for connecting a PC to a CAN network in applications with low performance requirements.

  • Economic passive board (no microprocessor on board)
  • Common driver interface for easy exchange of the PC interface typ
  • Available with one or two CAN channels
  • Galvanic isolation optional
PC bus interfacePC/104 bus, 8 bit
PC address rangeC000h-FFC0h (memory mapped), adjustable in 1 kB steps
InterruptsIRQ 3, 4, 5, 6, 7, 9, 10, 11, 12, 14, 15 separated for each CAN controller, shared interrupt, edge/level mode
CAN controllerSJA 1000; CAN 2.0 A/B
CAN bus interfaceISO 11898-2, bent 2 x 5 pin connectors according to CiA 303-1
Power supply5 V DC, 150 mA typ.
Galvanic isolationoptional (1 kV, 1 sec.)
Temperature range -20 ºC ... +70 ºC
CertificationCE, CSA/UL
SizeApprox. 90 x 96 mm

PC-I 04/104

IXXAT

Código: 1.01.0070.11110

Passive PC/104 board

1-2 x CAN (High-Speed)

The PC-I 04/104 represents a low-priced solution for connecting a PC to a CAN network in applications with low performance requirements.

  • Economic passive board (no microprocessor on board)
  • Common driver interface for easy exchange of the PC interface typ
  • Available with one or two CAN channels
  • Galvanic isolation optional
PC bus interfacePC/104 bus, 8 bit
PC address rangeC000h-FFC0h (memory mapped), adjustable in 1 kB steps
InterruptsIRQ 3, 4, 5, 6, 7, 9, 10, 11, 12, 14, 15 separated for each CAN controller, shared interrupt, edge/level mode
CAN controllerSJA 1000; CAN 2.0 A/B
CAN bus interfaceISO 11898-2, bent 2 x 5 pin connectors according to CiA 303-1
Power supply5 V DC, 150 mA typ.
Galvanic isolationoptional (1 kV, 1 sec.)
Temperature range -20 ºC ... +70 ºC
CertificationCE, CSA/UL
SizeApprox. 90 x 96 mm

PC-I 04/104

IXXAT

Código: 1.01.0070.11220

Passive PC/104 board

1-2 x CAN (High-Speed)

The PC-I 04/104 represents a low-priced solution for connecting a PC to a CAN network in applications with low performance requirements.

  • Economic passive board (no microprocessor on board)
  • Common driver interface for easy exchange of the PC interface typ
  • Available with one or two CAN channels
  • Galvanic isolation optional
PC bus interfacePC/104 bus, 8 bit
PC address rangeC000h-FFC0h (memory mapped), adjustable in 1 kB steps
InterruptsIRQ 3, 4, 5, 6, 7, 9, 10, 11, 12, 14, 15 separated for each CAN controller, shared interrupt, edge/level mode
CAN controllerSJA 1000; CAN 2.0 A/B
CAN bus interfaceISO 11898-2, bent 2 x 5 pin connectors according to CiA 303-1
Power supply5 V DC, 150 mA typ.
Galvanic isolationoptional (1 kV, 1 sec.)
Temperature range -20 ºC ... +70 ºC
CertificationCE, CSA/UL
SizeApprox. 90 x 96 mm

PC-I 04/104

IXXAT

Código: 1.01.0288.11003

Active USB interface

2 x CAN (High-/Low-Speed), LIN

The USB-to-CAN V2 Plugin enables the simple design in of a CAN interface into customer devices. At this, the compact dimensions predestine the use in applic

  • Cost-effective and extremely versatile
  • Compact dimensions
  • Common driver interface for easy exchange of the PC interface type
  • For industrial and automotive applications
  • Galvanic isolation optional
PC bus interface USB 2.0, Hi-Speed
Microcontroller 32 bit
CAN controller Internal; CAN 2.0 A/B
CAN baudrates 10 kBit/s ... 1 Mbit/s
CAN high-speed transceiver TI SN65HVD251D
CAN low-speed transceiver (1) TJA1055T
LIN transceiver (1) TJA1020
LIN protocol (1) V1.3 and V2.0
LIN baudrate (1) max. 20 kBaud
Galvanic isolation optional, 1 kV, 1 sec.
Power supply 5 V, max. 500 mA via USB port
Temperature range -40°C ... 85°C
Fieldbus connection single row female header; 2,54 pitch
USB connection single row female header; 2,54 pitch
Dimension 67.5 x 40 x 9.2 mm
Weight max. 15 g
Certification CE, EN 55022:2010, EN61000-6-1:2007

USB-to-CAN V2 Plugin

IXXAT

Código: 1.01.0288.12003

Active USB interface

2 x CAN (High-/Low-Speed), LIN

The USB-to-CAN V2 Plugin enables the simple design in of a CAN interface into customer devices. At this, the compact dimensions predestine the use in applic

  • Cost-effective and extremely versatile
  • Compact dimensions
  • Common driver interface for easy exchange of the PC interface type
  • For industrial and automotive applications
  • Galvanic isolation optional
PC bus interface USB 2.0, Hi-Speed
Microcontroller 32 bit
CAN controller Internal; CAN 2.0 A/B
CAN baudrates 10 kBit/s ... 1 Mbit/s
CAN high-speed transceiver TI SN65HVD251D
CAN low-speed transceiver (1) TJA1055T
LIN transceiver (1) TJA1020
LIN protocol (1) V1.3 and V2.0
LIN baudrate (1) max. 20 kBaud
Galvanic isolation optional, 1 kV, 1 sec.
Power supply 5 V, max. 500 mA via USB port
Temperature range -40°C ... 85°C
Fieldbus connection single row female header; 2,54 pitch
USB connection single row female header; 2,54 pitch
Dimension 67.5 x 40 x 9.2 mm
Weight max. 15 g
Certification CE, EN 55022:2010, EN61000-6-1:2007

USB-to-CAN V2 Plugin

IXXAT

Código: 1.01.0288.22003

Active USB interface

2 x CAN (High-/Low-Speed), LIN

The USB-to-CAN V2 Plugin enables the simple design in of a CAN interface into customer devices. At this, the compact dimensions predestine the use in applic

  • Cost-effective and extremely versatile
  • Compact dimensions
  • Common driver interface for easy exchange of the PC interface type
  • For industrial and automotive applications
  • Galvanic isolation optional
PC bus interface USB 2.0, Hi-Speed
Microcontroller 32 bit
CAN controller Internal; CAN 2.0 A/B
CAN baudrates 10 kBit/s ... 1 Mbit/s
CAN high-speed transceiver TI SN65HVD251D
CAN low-speed transceiver (1) TJA1055T
LIN transceiver (1) TJA1020
LIN protocol (1) V1.3 and V2.0
LIN baudrate (1) max. 20 kBaud
Galvanic isolation optional, 1 kV, 1 sec.
Power supply 5 V, max. 500 mA via USB port
Temperature range -40°C ... 85°C
Fieldbus connection single row female header; 2,54 pitch
USB connection single row female header; 2,54 pitch
Dimension 67.5 x 40 x 9.2 mm
Weight max. 15 g
Certification CE, EN 55022:2010, EN61000-6-1:2007

USB-to-CAN V2 Plugin

IXXAT

Código: 1.01.0288.22043

Active USB interface

2 x CAN (High-/Low-Speed), LIN

The USB-to-CAN V2 Plugin enables the simple design in of a CAN interface into customer devices. At this, the compact dimensions predestine the use in applic

  • Cost-effective and extremely versatile
  • Compact dimensions
  • Common driver interface for easy exchange of the PC interface type
  • For industrial and automotive applications
  • Galvanic isolation optional
PC bus interface USB 2.0, Hi-Speed
Microcontroller 32 bit
CAN controller Internal; CAN 2.0 A/B
CAN baudrates 10 kBit/s ... 1 Mbit/s
CAN high-speed transceiver TI SN65HVD251D
CAN low-speed transceiver (1) TJA1055T
LIN transceiver (1) TJA1020
LIN protocol (1) V1.3 and V2.0
LIN baudrate (1) max. 20 kBaud
Galvanic isolation optional, 1 kV, 1 sec.
Power supply 5 V, max. 500 mA via USB port
Temperature range -40°C ... 85°C
Fieldbus connection single row female header; 2,54 pitch
USB connection single row female header; 2,54 pitch
Dimension 67.5 x 40 x 9.2 mm
Weight max. 15 g
Certification CE, EN 55022:2010, EN61000-6-1:2007

USB-to-CAN V2 Plugin

IXXAT

Código: 1.01.0057.10100

Passive PCI board

1-2 x CAN (High-Speed)

The PC-I 04/PCI represents a low-priced solution for connecting a PC to a CAN network in applications with low performance requirements.

This pr
  • Economic passive board (no microprocessor on board)
  • Common driver interface for easy exchange of the PC interface type
  • Available with one or two CAN channels
  • Galvanic isolation optional
PC bus interface PCI Bus (V 2.1), 32 Bit, 33MHz, 5V
PC address range Plug & Play, 1024 bytes memory mapped and 128 bytes I/O area
Interrupts INT A, Plug & Play
CAN controller SJA 1000; CAN 2.0 A/B
CAN bus interface ISO 11898-2, Sub D9 connector according to CiA 303-1
Power supply 5 V DC, 300 mA typ.
Temperatur range -20 ºC ... +70 ºC
Galvanic isolation optional (1 kV, 1 sec.)
Certification CE, CSA/UL
Size Approx. 95 x 125 mm

PC-I 04/PCI

IXXAT

Código: 1.01.0057.10200

Passive PCI board

1-2 x CAN (High-Speed)

The PC-I 04/PCI represents a low-priced solution for connecting a PC to a CAN network in applications with low performance requirements.

This pr
  • Economic passive board (no microprocessor on board)
  • Common driver interface for easy exchange of the PC interface type
  • Available with one or two CAN channels
  • Galvanic isolation optional
PC bus interface PCI Bus (V 2.1), 32 Bit, 33MHz, 5V
PC address range Plug & Play, 1024 bytes memory mapped and 128 bytes I/O area
Interrupts INT A, Plug & Play
CAN controller SJA 1000; CAN 2.0 A/B
CAN bus interface ISO 11898-2, Sub D9 connector according to CiA 303-1
Power supply 5 V DC, 300 mA typ.
Temperatur range -20 ºC ... +70 ºC
Galvanic isolation optional (1 kV, 1 sec.)
Certification CE, CSA/UL
Size Approx. 95 x 125 mm

PC-I 04/PCI

IXXAT

Código: 1.01.0057.11220

Passive PCI board

1-2 x CAN (High-Speed)

The PC-I 04/PCI represents a low-priced solution for connecting a PC to a CAN network in applications with low performance requirements.

This pr
  • Economic passive board (no microprocessor on board)
  • Common driver interface for easy exchange of the PC interface type
  • Available with one or two CAN channels
  • Galvanic isolation optional
PC bus interface PCI Bus (V 2.1), 32 Bit, 33MHz, 5V
PC address range Plug & Play, 1024 bytes memory mapped and 128 bytes I/O area
Interrupts INT A, Plug & Play
CAN controller SJA 1000; CAN 2.0 A/B
CAN bus interface ISO 11898-2, Sub D9 connector according to CiA 303-1
Power supply 5 V DC, 300 mA typ.
Temperatur range -20 ºC ... +70 ºC
Galvanic isolation optional (1 kV, 1 sec.)
Certification CE, CSA/UL
Size Approx. 95 x 125 mm

PC-I 04/PCI

IXXAT

Código: 1.01.0043.10200

Active PC/104 board

1 x CAN (High-Speed)

The iPC-I 320/104 is an active CAN board with one CAN channel which is appropriate for a wide variety of CAN applications. Filtering, preprocessing, transmission and time-stamped

  • Active CAN board with 8 bit micro controller
  • Common driver interface for easy exchange of the PC interface type
  • Features filtering, preprocessing, time stamped storage of CAN messages
  • Galvanic isolated CAN interface
PC bus interface PC/104 bus, 8 bit
PC address range C000h-FE00h (memory mapped), adjustable in 8 kB steps
Interrupts IRQ 3, 4, 5, 6, 7, 9, 10, 11, 12, 14, 15
Microcontroller Dallas DS80C320
CAN controller SJA 1000; CAN 2.0 A/B
CAN bus interface ISO 11898-2, bent 2 x 5 pin connector according to DS 102
Power supply 5 V DC, 190 mA typ.
Galvanic isolation 1 kV, 1 sec.
Temperature range -40 ºC ... +85 ºC
Certification CE, CSA/UL
Size Approx. 90 x 96 mm

iPC-I 320/104

IXXAT

Código: CAN-IB410-PMC

Active PMC board

1-4 x CAN (High-/Low-Speed), LIN

(New product: available June 2016)

With the CAN-IB410/PMC HMS offers an interface board based on a modern and highly m

  • Active board with 32 bit microcontroller
  • Easy expandable via field bus expansion and expansion board
  • Up to four CAN channels (High-/Low-Speed optional switchable)
  • LIN optional
  • Galvanic isolation
  • Common driver interface for easy exchange of the PC interface type
PC bus interface PMC
PC address range Plug & Play
Interrupts Plug & Play
Microcontroller 32 bit microcontroller
CAN interface 1, 2 or 4 CAN interfaces; CAN 2.0 A/B; Sub-D9 plug according to CiA 303-1; Galvanic isolation (1 kV, 1 sec.) Optional: CAN Low-Speed (switchable via software between CAN High-Speed and Low-Speed)
LIN/K-Line interface Optional: up to 2 LIN (ISO 9141) interfaces; Sub-D9 plug
Power supply 3.3 V DC, 650 mA typ.
Temperature range -20 ºC ... +70 ºC
Certification  CE
Size Approx. 74 x 149 mm

CAN-IB410/PMC

IXXAT

Código: 1.01.0049.33660

Active PMC board

2 x CAN (High-/Low-Speed), LIN

The iPC-I XC16/PMC is an active PMC board for 5 V and 3.3 V PMC bus systems with high/low-speed CAN interface and LIN interface. The on-board microcontroller offers f

  • Active CAN board with 16 bit microcontroller
  • Common driver interface for easy exchange of the PC interface type
  • Features filtering, preprocessing, time stamped storage of CAN messages
  • High-/Low-Speed CAN bus interface
  • LIN interface
  • Galvanic isolation
PC bus interface PMC Bus (V2.2), 32 Bit / 33 MHz, 5 Volt or 3.3 Volt
Memory range Plug & Play, 16 kB memory mapped and 128 bytes I/O area
Interrupts INT A, Plug & Play
Microcontroller Infineon XC161
CAN controller TwinCAN (two CAN channels); CAN 2.0 A/B
CAN bus interface ISO 11898-2 and ISO 11898-3, Sub D9 connector according to CiA 303-1, high-/low-speed bus interface switchable via software
LIN controller TJA1020
LIN bus interface ISO 9141/LIN, Master/Slave mode switchable via software, galvanic isolation
Power supply 5 V DC, 100 mA typ.; 3.3 V DC, 120 mA typ.
Galvanic isolation 1 kV, 1 sec.
Temperature range -20 ºC ... +70 ºC
Certification CE, FCC
Size Approx. 74 x 149 mm single CMC

iPC-I XC16/PMC

IXXAT

Código: CAN-IB210-XMC

Active XMC board

1-4 x CAN (High-/Low-Speed), LIN

(New product: available June 2016)

With the CAN-IB210/XMC HMS offers an interface board based on a modern and highly m

  • Active board with 32 bit microcontroller
  • Easy expandable via field bus expansion and expansion board
  • Up to four CAN channels (High-/Low-Speed optional switchable)
  • LIN optional
  • Galvanic isolation
  • Common driver interface for easy exchange of the PC interface type
PC bus interface XMC
PC address range Plug & Play
Interrupts Plug & Play
Microcontroller 32 bit microcontroller
CAN interface 1, 2 or 4 CAN interfaces; CAN 2.0 A/B; Sub-D9 plug according to CiA 303-1; Galvanic isolation (1 kV, 1 sec.) Optional: CAN Low-Speed (switchable via software between CAN High-Speed and Low-Speed)
LIN/K-Line interface Optional: up to 2 LIN (ISO 9141) interfaces; Sub-D9 plug
Power supply 3.3 V DC, 600 mA typ.
Temperature range -20 ºC ... +70 ºC
Certification  CE
Size Approx. 74 x 149 mm

CAN-IB210/XMC

IXXAT

Código: 1.01.0047.33110

Active PCI board

1-2 x CAN (High-/Low-Speed)

The iPC-I XC16/PCI is an active CAN PCI interface for 5 V and 3.3 V PCI bus systems with optional Low-Speed bus interface. The on-board microcontroller offers filtering, prep

  • Active CAN board with 16 bit microcontroller
  • Common driver interface for easy exchange of the PC interface type
  • Features filtering, preprocessing, time stamped storage of CAN messages
  • High-/Low-Speed bus interface optional
  • Galvanic isolation optional
PC bus interface PCI-Bus (V2.2), 32 Bit / 33 MHz, 5 Volt or 3.3 Volt
PC address range Plug & Play, 16 kB memory mapped and 128 bytes I/O area
Interrupts INT A, Plug & Play
Microcontroller Infineon XC161
CAN controller TwinCAN (two CAN channels); CAN 2.0 A/B
CAN bus interface ISO 11898-2 according to CiA 303-1, Sub D9 connector, optional high-/low-speed bus interface (ISO 11898-3) switchable via software
Power supply 5 V DC, 100 mA typ.; 3.3 V DC, 185 mA typ.
Galvanic isolation optional (1 kV, 1 sec.)
Temperature range -20 ºC ... +70 ºC
Certification CE, CSA/UL, FCC, EN 60601-1
Size Approx. 123 x 90 mm

iPC-I XC16/PCI

Actualmente estamos trabajando en mostrarte los mejores resultados, si no encuentras el producto que buscas contacta con nosotros a través de info@er-soft.com o al número Tel. +34 916-408-408
Bienvenido a ER-Soft.
ER-Soft con la ley orgánica de protección de datos
Política de cookies.
Utilizamos cookies propias y de terceros para mejorar nuestros servicios y mostrarle publicidad relacionada con sus preferencias mediante el análisis de sus hábitos de navegación.
Si continúa navegando, consideramos que acepta su uso.
Más información pulsando aquí
X

¿Necesitas ayuda? Click

ayuda ER-Soft
X
Consulta a ER-Soft. *



*



* *Campos obligatorios.




*Al enviar el formulario consideramos que esta de acuerdo, con nuestra política de datos. Ver política de datos
X
