IXXAT

Código: 1.01.0291.11000

Passive PCI board

1-4 x CAN (High-/Low-Speed)

With the CAN-IB300/PCI IXXAT offers an interface board based on a modern and highly modular concept. The interface is available with a standard or a low-profile slot bracket

  • Economically priced passive board (no microprocessor on board)
  • Easy expandable via field bus expansion and expansion board
  • Up to four CAN channels (High-/Low-Speed optional switchable)
  • Available as standard and low-profile version
  • Galvanic isolation optional
  • Common driver interface for easy exchange of the PC interface type
PC bus interface PCI (V2.2)
PC address range Plug & Play
Interrupts Plug & Play
CAN interface 11, 2 or 4 CAN interfaces; CAN 2.0 A/B; Sub-D9 plug according to CiA 303-1 Optional: CAN Low-Speed (switchable via software between CAN High-Speed and Low-Speed) Optional: Galvanic isolation (1 kV, 1 sec.)
Power supply typ. 3.3 V DC, 100 mA / 5 V DC, 100 mA
Temperature range 0 ºC ... +70 ºC
Certification CE, FCC
Size Approx. 65 x 120 mm (available as standard and low-profile version)

CAN-IB300/PCI

IXXAT

Código: 1.01.0291.12001

Passive PCI board

1-4 x CAN (High-/Low-Speed)

With the CAN-IB300/PCI IXXAT offers an interface board based on a modern and highly modular concept. The interface is available with a standard or a low-profile slot bracket

  • Economically priced passive board (no microprocessor on board)
  • Easy expandable via field bus expansion and expansion board
  • Up to four CAN channels (High-/Low-Speed optional switchable)
  • Available as standard and low-profile version
  • Galvanic isolation optional
  • Common driver interface for easy exchange of the PC interface type
PC bus interface PCI (V2.2)
PC address range Plug & Play
Interrupts Plug & Play
CAN interface 11, 2 or 4 CAN interfaces; CAN 2.0 A/B; Sub-D9 plug according to CiA 303-1 Optional: CAN Low-Speed (switchable via software between CAN High-Speed and Low-Speed) Optional: Galvanic isolation (1 kV, 1 sec.)
Power supply typ. 3.3 V DC, 100 mA / 5 V DC, 100 mA
Temperature range 0 ºC ... +70 ºC
Certification CE, FCC
Size Approx. 65 x 120 mm (available as standard and low-profile version)

CAN-IB300/PCI

IXXAT

Código: 1.01.0291.22001

Passive PCI board

1-4 x CAN (High-/Low-Speed)

With the CAN-IB300/PCI IXXAT offers an interface board based on a modern and highly modular concept. The interface is available with a standard or a low-profile slot bracket

  • Economically priced passive board (no microprocessor on board)
  • Easy expandable via field bus expansion and expansion board
  • Up to four CAN channels (High-/Low-Speed optional switchable)
  • Available as standard and low-profile version
  • Galvanic isolation optional
  • Common driver interface for easy exchange of the PC interface type
PC bus interface PCI (V2.2)
PC address range Plug & Play
Interrupts Plug & Play
CAN interface 11, 2 or 4 CAN interfaces; CAN 2.0 A/B; Sub-D9 plug according to CiA 303-1 Optional: CAN Low-Speed (switchable via software between CAN High-Speed and Low-Speed) Optional: Galvanic isolation (1 kV, 1 sec.)
Power supply typ. 3.3 V DC, 100 mA / 5 V DC, 100 mA
Temperature range 0 ºC ... +70 ºC
Certification CE, FCC
Size Approx. 65 x 120 mm (available as standard and low-profile version)

CAN-IB300/PCI

IXXAT

Código: 1.01.0292.12001

Passive PCI board

1-4 x CAN (High-/Low-Speed)

With the CAN-IB300/PCI IXXAT offers an interface board based on a modern and highly modular concept. The interface is available with a standard or a low-profile slot bracket

  • Economically priced passive board (no microprocessor on board)
  • Easy expandable via field bus expansion and expansion board
  • Up to four CAN channels (High-/Low-Speed optional switchable)
  • Available as standard and low-profile version
  • Galvanic isolation optional
  • Common driver interface for easy exchange of the PC interface type
PC bus interface PCI (V2.2)
PC address range Plug & Play
Interrupts Plug & Play
CAN interface 11, 2 or 4 CAN interfaces; CAN 2.0 A/B; Sub-D9 plug according to CiA 303-1 Optional: CAN Low-Speed (switchable via software between CAN High-Speed and Low-Speed) Optional: Galvanic isolation (1 kV, 1 sec.)
Power supply typ. 3.3 V DC, 100 mA / 5 V DC, 100 mA
Temperature range 0 ºC ... +70 ºC
Certification CE, FCC
Size Approx. 65 x 120 mm (available as standard and low-profile version)

CAN-IB300/PCI

IXXAT

Código: 1.01.0292.22001

Passive PCI board

1-4 x CAN (High-/Low-Speed)

With the CAN-IB300/PCI IXXAT offers an interface board based on a modern and highly modular concept. The interface is available with a standard or a low-profile slot bracket

  • Economically priced passive board (no microprocessor on board)
  • Easy expandable via field bus expansion and expansion board
  • Up to four CAN channels (High-/Low-Speed optional switchable)
  • Available as standard and low-profile version
  • Galvanic isolation optional
  • Common driver interface for easy exchange of the PC interface type
PC bus interface PCI (V2.2)
PC address range Plug & Play
Interrupts Plug & Play
CAN interface 11, 2 or 4 CAN interfaces; CAN 2.0 A/B; Sub-D9 plug according to CiA 303-1 Optional: CAN Low-Speed (switchable via software between CAN High-Speed and Low-Speed) Optional: Galvanic isolation (1 kV, 1 sec.)
Power supply typ. 3.3 V DC, 100 mA / 5 V DC, 100 mA
Temperature range 0 ºC ... +70 ºC
Certification CE, FCC
Size Approx. 65 x 120 mm (available as standard and low-profile version)

CAN-IB300/PCI

IXXAT

Código: 1.01.0293.11000

Active PCI board

1-4 x CAN (High-/Low-Speed), LIN, K-Line

With the CAN-IB400/PCI HMS offers an interface board based on a modern and highly modular concept. The board covers the entire range of field buses, such as

  • Active board with 32 bit microcontroller
  • Easy expandable via field bus expansion and expansion board
  • Up to four CAN channels (High-/Low-Speed optional switchable)
  • LIN and K-Line optional
  • Available as standard and low-profile version
  • Galvanic isolation optional
  • Common driver interface for easy exchange of the PC interface type
PC bus interface PCI (V2.2)
PC address range Plug & Play
Interrupts Plug & Play
Microcontroller 32 bit microcontroller
CAN interface 1, 2 or 4 CAN interfaces; CAN 2.0 A/B; Sub-D9 plug according to CiA 303-1 Optional: CAN Low-Speed (switchable via software between CAN High-Speed and Low-Speed) Optional: Galvanic isolation (1 kV, 1 sec.)
LIN/K-Line interface Optional: up to 4 LIN (ISO 9141) or K-Line interfaces; Sub-D9 plug
Power supply typ. 3.3 V DC, 500 mA / 5 V DC, 100 mA
Temperature range 0 ºC ... +70 ºC
Certification  CE, FCC
Size Approx. 65 x 120 mm (available as standard and low-profile version)

CAN-IB400/PCI

IXXAT

Código: 1.01.0293.12001

Active PCI board

1-4 x CAN (High-/Low-Speed), LIN, K-Line

With the CAN-IB400/PCI HMS offers an interface board based on a modern and highly modular concept. The board covers the entire range of field buses, such as

  • Active board with 32 bit microcontroller
  • Easy expandable via field bus expansion and expansion board
  • Up to four CAN channels (High-/Low-Speed optional switchable)
  • LIN and K-Line optional
  • Available as standard and low-profile version
  • Galvanic isolation optional
  • Common driver interface for easy exchange of the PC interface type
PC bus interface PCI (V2.2)
PC address range Plug & Play
Interrupts Plug & Play
Microcontroller 32 bit microcontroller
CAN interface 1, 2 or 4 CAN interfaces; CAN 2.0 A/B; Sub-D9 plug according to CiA 303-1 Optional: CAN Low-Speed (switchable via software between CAN High-Speed and Low-Speed) Optional: Galvanic isolation (1 kV, 1 sec.)
LIN/K-Line interface Optional: up to 4 LIN (ISO 9141) or K-Line interfaces; Sub-D9 plug
Power supply typ. 3.3 V DC, 500 mA / 5 V DC, 100 mA
Temperature range 0 ºC ... +70 ºC
Certification  CE, FCC
Size Approx. 65 x 120 mm (available as standard and low-profile version)

CAN-IB400/PCI

IXXAT

Código: 1.01.0293.21000

Active PCI board

1-4 x CAN (High-/Low-Speed), LIN, K-Line

With the CAN-IB400/PCI HMS offers an interface board based on a modern and highly modular concept. The board covers the entire range of field buses, such as

  • Active board with 32 bit microcontroller
  • Easy expandable via field bus expansion and expansion board
  • Up to four CAN channels (High-/Low-Speed optional switchable)
  • LIN and K-Line optional
  • Available as standard and low-profile version
  • Galvanic isolation optional
  • Common driver interface for easy exchange of the PC interface type
PC bus interface PCI (V2.2)
PC address range Plug & Play
Interrupts Plug & Play
Microcontroller 32 bit microcontroller
CAN interface 1, 2 or 4 CAN interfaces; CAN 2.0 A/B; Sub-D9 plug according to CiA 303-1 Optional: CAN Low-Speed (switchable via software between CAN High-Speed and Low-Speed) Optional: Galvanic isolation (1 kV, 1 sec.)
LIN/K-Line interface Optional: up to 4 LIN (ISO 9141) or K-Line interfaces; Sub-D9 plug
Power supply typ. 3.3 V DC, 500 mA / 5 V DC, 100 mA
Temperature range 0 ºC ... +70 ºC
Certification  CE, FCC
Size Approx. 65 x 120 mm (available as standard and low-profile version)

CAN-IB400/PCI

IXXAT

Código: 1.01.0293.22001

Active PCI board

1-4 x CAN (High-/Low-Speed), LIN, K-Line

With the CAN-IB400/PCI HMS offers an interface board based on a modern and highly modular concept. The board covers the entire range of field buses, such as

  • Active board with 32 bit microcontroller
  • Easy expandable via field bus expansion and expansion board
  • Up to four CAN channels (High-/Low-Speed optional switchable)
  • LIN and K-Line optional
  • Available as standard and low-profile version
  • Galvanic isolation optional
  • Common driver interface for easy exchange of the PC interface type
PC bus interface PCI (V2.2)
PC address range Plug & Play
Interrupts Plug & Play
Microcontroller 32 bit microcontroller
CAN interface 1, 2 or 4 CAN interfaces; CAN 2.0 A/B; Sub-D9 plug according to CiA 303-1 Optional: CAN Low-Speed (switchable via software between CAN High-Speed and Low-Speed) Optional: Galvanic isolation (1 kV, 1 sec.)
LIN/K-Line interface Optional: up to 4 LIN (ISO 9141) or K-Line interfaces; Sub-D9 plug
Power supply typ. 3.3 V DC, 500 mA / 5 V DC, 100 mA
Temperature range 0 ºC ... +70 ºC
Certification  CE, FCC
Size Approx. 65 x 120 mm (available as standard and low-profile version)

CAN-IB400/PCI

IXXAT

Código: 1.01.0294.12001

Active PCI board

1-4 x CAN (High-/Low-Speed), LIN, K-Line

With the CAN-IB400/PCI HMS offers an interface board based on a modern and highly modular concept. The board covers the entire range of field buses, such as

  • Active board with 32 bit microcontroller
  • Easy expandable via field bus expansion and expansion board
  • Up to four CAN channels (High-/Low-Speed optional switchable)
  • LIN and K-Line optional
  • Available as standard and low-profile version
  • Galvanic isolation optional
  • Common driver interface for easy exchange of the PC interface type
PC bus interface PCI (V2.2)
PC address range Plug & Play
Interrupts Plug & Play
Microcontroller 32 bit microcontroller
CAN interface 1, 2 or 4 CAN interfaces; CAN 2.0 A/B; Sub-D9 plug according to CiA 303-1 Optional: CAN Low-Speed (switchable via software between CAN High-Speed and Low-Speed) Optional: Galvanic isolation (1 kV, 1 sec.)
LIN/K-Line interface Optional: up to 4 LIN (ISO 9141) or K-Line interfaces; Sub-D9 plug
Power supply typ. 3.3 V DC, 500 mA / 5 V DC, 100 mA
Temperature range 0 ºC ... +70 ºC
Certification  CE, FCC
Size Approx. 65 x 120 mm (available as standard and low-profile version)

CAN-IB400/PCI

IXXAT

Código: 1.01.0294.22001

Active PCI board

1-4 x CAN (High-/Low-Speed), LIN, K-Line

With the CAN-IB400/PCI HMS offers an interface board based on a modern and highly modular concept. The board covers the entire range of field buses, such as

  • Active board with 32 bit microcontroller
  • Easy expandable via field bus expansion and expansion board
  • Up to four CAN channels (High-/Low-Speed optional switchable)
  • LIN and K-Line optional
  • Available as standard and low-profile version
  • Galvanic isolation optional
  • Common driver interface for easy exchange of the PC interface type
PC bus interface PCI (V2.2)
PC address range Plug & Play
Interrupts Plug & Play
Microcontroller 32 bit microcontroller
CAN interface 1, 2 or 4 CAN interfaces; CAN 2.0 A/B; Sub-D9 plug according to CiA 303-1 Optional: CAN Low-Speed (switchable via software between CAN High-Speed and Low-Speed) Optional: Galvanic isolation (1 kV, 1 sec.)
LIN/K-Line interface Optional: up to 4 LIN (ISO 9141) or K-Line interfaces; Sub-D9 plug
Power supply typ. 3.3 V DC, 500 mA / 5 V DC, 100 mA
Temperature range 0 ºC ... +70 ºC
Certification  CE, FCC
Size Approx. 65 x 120 mm (available as standard and low-profile version)

CAN-IB400/PCI

IXXAT

Código: 1.01.0231.12010

Passive PCI Express board

1 x CAN (High-Speed), CAN FD

With the CAN-IB500/PCIe HMS offers a CAN FD interface based on a modern and highly modular architecture concept. The interface has one CAN channel which can se

  • Economically priced passive board (no microprocessor on board)
  • One CAN channel (High-Speed CAN or CAN FD)
  • Available as standard and low-profile version
  • Galvanic isolation
  • Common driver interface for easy exchange of the PC interface type
PC bus interface PCI express (V1.1)
PC address range Plug & Play
Interrupts Plug & Play
CAN interface 1 CAN channel; CAN FD or CAN 2.0 A/B; Sub-D9 plugs according to CiA 303-1, galvanic isolation (1 kV, 1 sec.)
Power supply 3.3 V DC, 400 mA typ.
Temperature range 0 ºC ... +70 ºC
Certification  CE, FCC
Size Approx. 65 x 105 mm (available as standard and low-profile version)

CAN-IB500/PCIe

IXXAT

Código: 1.01.0233.12010

Active PCI Express board

1-2 x CAN (High-Speed), CAN FD

With the CAN-IB600/PCIe HMS offers a CAN FD interface based on a modern and highly modular architecture concept. The interface is available with up to two CAN

  • Active board with 32 bit microcontroller
  • Up to two CAN channels (High-Speed CAN or CAN FD)
  • Available as standard and low-profile version
  • Galvanic isolation
  • Common driver interface for easy exchange of the PC interface type
PC bus interface PCI express (V1.1)
PC address range Plug & Play
Interrupts Plug & Play
Microcontroller 32 bit microcontroller
CAN interface 1 or 2 CAN channels; CAN FD or CAN 2.0 A/B; Sub-D9 plugs according to CiA 303-1, galvanic isolation (1 kV, 1 sec.)
Power supply 3.3 V DC, 400 mA typ.
Temperature range 0 ºC ... +70 ºC
Certification  CE, FCC
Size Approx. 65 x 105 mm (available as standard and low-profile version)

CAN-IB600/PCIe

IXXAT

Código: 1.01.0233.22010

Active PCI Express board

1-2 x CAN (High-Speed), CAN FD

With the CAN-IB600/PCIe HMS offers a CAN FD interface based on a modern and highly modular architecture concept. The interface is available with up to two CAN

  • Active board with 32 bit microcontroller
  • Up to two CAN channels (High-Speed CAN or CAN FD)
  • Available as standard and low-profile version
  • Galvanic isolation
  • Common driver interface for easy exchange of the PC interface type
PC bus interface PCI express (V1.1)
PC address range Plug & Play
Interrupts Plug & Play
Microcontroller 32 bit microcontroller
CAN interface 1 or 2 CAN channels; CAN FD or CAN 2.0 A/B; Sub-D9 plugs according to CiA 303-1, galvanic isolation (1 kV, 1 sec.)
Power supply 3.3 V DC, 400 mA typ.
Temperature range 0 ºC ... +70 ºC
Certification  CE, FCC
Size Approx. 65 x 105 mm (available as standard and low-profile version)

CAN-IB600/PCIe

IXXAT

Código: 1.01.0070.10100

Passive PC/104 board

1-2 x CAN (High-Speed)

The PC-I 04/104 represents a low-priced solution for connecting a PC to a CAN network in applications with low performance requirements.

  • Economic passive board (no microprocessor on board)
  • Common driver interface for easy exchange of the PC interface typ
  • Available with one or two CAN channels
  • Galvanic isolation optional
PC bus interfacePC/104 bus, 8 bit
PC address rangeC000h-FFC0h (memory mapped), adjustable in 1 kB steps
InterruptsIRQ 3, 4, 5, 6, 7, 9, 10, 11, 12, 14, 15 separated for each CAN controller, shared interrupt, edge/level mode
CAN controllerSJA 1000; CAN 2.0 A/B
CAN bus interfaceISO 11898-2, bent 2 x 5 pin connectors according to CiA 303-1
Power supply5 V DC, 150 mA typ.
Galvanic isolationoptional (1 kV, 1 sec.)
Temperature range -20 ºC ... +70 ºC
CertificationCE, CSA/UL
SizeApprox. 90 x 96 mm

PC-I 04/104

Actualmente estamos trabajando en mostrarte los mejores resultados, si no encuentras el producto que buscas contacta con nosotros a través de info@er-soft.com o al número Tel. +34 916-408-408
Bienvenido a ER-Soft.
ER-Soft con la ley orgánica de protección de datos
Política de cookies.
Utilizamos cookies propias y de terceros para mejorar nuestros servicios y mostrarle publicidad relacionada con sus preferencias mediante el análisis de sus hábitos de navegación.
Si continúa navegando, consideramos que acepta su uso.
Más información pulsando aquí
X

¿Necesitas ayuda? Click

ayuda ER-Soft
X
Consulta a ER-Soft. *



*



* *Campos obligatorios.




*Al enviar el formulario consideramos que esta de acuerdo, con nuestra política de datos. Ver política de datos
X
