IXXAT

Código: 1.01.0320.25120

Versatile industrial Ethernet PC interface for Powerlink

The dedicated Powerlink version of the IXXAT INpact comes with a pre-installed network protocol. It enables the easy connection of PC-based Powerlink Sl

    undefined
 INpact CE Slave PCIe Standard/Low Profile INpact CE Slave PCIe Mini
Field bus interface Two Ethernet ports, 100/10 Mbit Two Ethernet ports, 100/10 Mbit
PC interfaces PCI Express single lane port (x1) according to PCI Express base specification, revision 1.1 Mini PCI Express (x1)
Network handling Anybus NP40 Anybus NP40
Power supply Via PCIe socket (3.3 V / 12 V DC) Via PCIe (3.3 V)
Current consumption Typ. 270 mA / 3.3 V DC, 110 mA / 12 V DC Typ. 600 mA / 3.3 V DC
Form factor Standard height / low profile PCI Express add-in card profile Full Mini Card form factor
Operating temperature range 0 °C to 70 °C Option: -40 °C to 70° C -40 °C to 60 °C
Dimensions  64 x 105 mm  30 x 50.95 x 12 mm (with cable)
Weight approx. 52 g approx. 26 g (board, cable, bus interface)

INpact EPL Slave PCIe

IXXAT

Código: 1.01.0340.25101

Versatile industrial Ethernet PC interface for Powerlink

The dedicated Powerlink version of the IXXAT INpact comes with a pre-installed network protocol. It enables the easy connection of PC-based Powerlink Sl

    undefined
 INpact CE Slave PCIe Standard/Low Profile INpact CE Slave PCIe Mini
Field bus interface Two Ethernet ports, 100/10 Mbit Two Ethernet ports, 100/10 Mbit
PC interfaces PCI Express single lane port (x1) according to PCI Express base specification, revision 1.1 Mini PCI Express (x1)
Network handling Anybus NP40 Anybus NP40
Power supply Via PCIe socket (3.3 V / 12 V DC) Via PCIe (3.3 V)
Current consumption Typ. 270 mA / 3.3 V DC, 110 mA / 12 V DC Typ. 600 mA / 3.3 V DC
Form factor Standard height / low profile PCI Express add-in card profile Full Mini Card form factor
Operating temperature range 0 °C to 70 °C Option: -40 °C to 70° C -40 °C to 60 °C
Dimensions  64 x 105 mm  30 x 50.95 x 12 mm (with cable)
Weight approx. 52 g approx. 26 g (board, cable, bus interface)

INpact EPL Slave PCIe

IXXAT

Código: 1.01.0320.23110

Versatile industrial Ethernet PC interface for Modbus-TCP

The dedicated Modbus-TCP version of the IXXAT INpact comes with a pre-installed network protocol. It enables the easy connection of PC-based Modbus-TCP

    undefined
 INpact CE Slave PCIe Standard/Low Profile INpact CE Slave PCIe Mini
Field bus interface Two Ethernet ports, 100/10 Mbit Two Ethernet ports, 100/10 Mbit
PC interfaces PCI Express single lane port (x1) according to PCI Express base specification, revision 1.1 Mini PCI Express (x1)
Network handling Anybus NP40 Anybus NP40
Power supply Via PCIe socket (3.3 V / 12 V DC) Via PCIe (3.3 V)
Current consumption Typ. 270 mA / 3.3 V DC, 110 mA / 12 V DC Typ. 600 mA / 3.3 V DC
Form factor Standard height / low profile PCI Express add-in card profile Full Mini Card form factor
Operating temperature range 0 °C to 70 °C Option: -40 °C to 70° C -40 °C to 60 °C
Dimensions  64 x 105 mm  30 x 50.95 x 12 mm (with cable)
Weight approx. 52 g approx. 26 g (board, cable, bus interface)

INpact EIT Slave PCIe

IXXAT

Código: 1.01.0320.23120

Versatile industrial Ethernet PC interface for Modbus-TCP

The dedicated Modbus-TCP version of the IXXAT INpact comes with a pre-installed network protocol. It enables the easy connection of PC-based Modbus-TCP

    undefined
 INpact CE Slave PCIe Standard/Low Profile INpact CE Slave PCIe Mini
Field bus interface Two Ethernet ports, 100/10 Mbit Two Ethernet ports, 100/10 Mbit
PC interfaces PCI Express single lane port (x1) according to PCI Express base specification, revision 1.1 Mini PCI Express (x1)
Network handling Anybus NP40 Anybus NP40
Power supply Via PCIe socket (3.3 V / 12 V DC) Via PCIe (3.3 V)
Current consumption Typ. 270 mA / 3.3 V DC, 110 mA / 12 V DC Typ. 600 mA / 3.3 V DC
Form factor Standard height / low profile PCI Express add-in card profile Full Mini Card form factor
Operating temperature range 0 °C to 70 °C Option: -40 °C to 70° C -40 °C to 60 °C
Dimensions  64 x 105 mm  30 x 50.95 x 12 mm (with cable)
Weight approx. 52 g approx. 26 g (board, cable, bus interface)

INpact EIT Slave PCIe

IXXAT

Código: 1.01.0340.23101

Versatile industrial Ethernet PC interface for Modbus-TCP

The dedicated Modbus-TCP version of the IXXAT INpact comes with a pre-installed network protocol. It enables the easy connection of PC-based Modbus-TCP

    undefined
 INpact CE Slave PCIe Standard/Low Profile INpact CE Slave PCIe Mini
Field bus interface Two Ethernet ports, 100/10 Mbit Two Ethernet ports, 100/10 Mbit
PC interfaces PCI Express single lane port (x1) according to PCI Express base specification, revision 1.1 Mini PCI Express (x1)
Network handling Anybus NP40 Anybus NP40
Power supply Via PCIe socket (3.3 V / 12 V DC) Via PCIe (3.3 V)
Current consumption Typ. 270 mA / 3.3 V DC, 110 mA / 12 V DC Typ. 600 mA / 3.3 V DC
Form factor Standard height / low profile PCI Express add-in card profile Full Mini Card form factor
Operating temperature range 0 °C to 70 °C Option: -40 °C to 70° C -40 °C to 60 °C
Dimensions  64 x 105 mm  30 x 50.95 x 12 mm (with cable)
Weight approx. 52 g approx. 26 g (board, cable, bus interface)

INpact EIT Slave PCIe

IXXAT

Código: 1.01.0103.00000

Cost effective FlexRay PCIexpress card for
analysis and control applications

The FR-IB100/PCIe is an extremely cost effective and high-performant interface card for FlexRay analysis and control applications as well as for a
    undefined
PC bus interface PCIe (r1.1), x1 link (2,5 Gbps per direction)
PC address range Plug & Play, 3 memory regions (8 kB, 32 kB, 2 MB)
Interrupts Plug & Play
Microcontroller 32 bit microcontroller
Memory 1 MByte
FlexRay interface 2 x 10 MBit/s, galvanic decoupled
FlexRay protocol chip MFR4310 protocol chip
Power Supply 3.3 V DC, 400 mA typ.
Temperature range 0 °C ... +70 °C
Certification CE, FCC
Dimensions approx. 106 mm x 58 mm

FR-IB100/PCIe

IXXAT

Código: 1.01.0109.00111

Powerlink PCI interface board for
analysis and control applications

The Powerlink interface board enables the connection of PC host systems to Powerlink systems via the PCI bus. The Powerlink functionality runs complete

    undefined

PL-IB 300/PCI

IXXAT

Código: 1.01.0109.00121

Powerlink PCI interface board for
analysis and control applications

The Powerlink interface board enables the connection of PC host systems to Powerlink systems via the PCI bus. The Powerlink functionality runs complete

    undefined

PL-IB 300/PCI

IXXAT

Código: 1.01.0300.00001

The IXXAT Safe T100 offers device manufacturers an easy way to control safe I/O signals using a safe fieldbus protocol. The module meets the SIL3 safety requirement level as defined by IEC 61508 and Performance Level PLe / Category 4 in IEC 13849-1.

  • All necessary functions and methods to achieve SIL-3/PLe on one board — simplifies customer board design
  • IOs configurable for single and dual channel use
  • Pre-certified concept and hardware for easy re-certification of the final device
  • Provision of full documentation set including TÜV type approval
  • Direct connectivity to Anybus CompactCom module for non-safe fieldbus communication - safe and non-safe communication on the same wire
Supported standards PROFIsafe (further versions for CIP Safety, FSoE and openSAFETY are under development)
Digital inputs 3 x dual channel, configurable with filter and monitor functions
Digital outputs 1 x dual channel, configurable
Safety Conformance Level max. SIL 3, PL e category 4
Power supply 24 V DC (SELV/PELV), 3.3 V DC
Environment temperature -30 °C to +68 °C
Dimensions 70 x 40 x 15 mm

IXXAT Safe T100

IXXAT

Código: 022830-B

The IXXAT Safe T100 offers device manufacturers an easy way to control safe I/O signals using a safe fieldbus protocol. The module meets the SIL3 safety requirement level as defined by IEC 61508 and Performance Level PLe / Category 4 in IEC 13849-1.

  • All necessary functions and methods to achieve SIL-3/PLe on one board — simplifies customer board design
  • IOs configurable for single and dual channel use
  • Pre-certified concept and hardware for easy re-certification of the final device
  • Provision of full documentation set including TÜV type approval
  • Direct connectivity to Anybus CompactCom module for non-safe fieldbus communication - safe and non-safe communication on the same wire
Supported standards PROFIsafe (further versions for CIP Safety, FSoE and openSAFETY are under development)
Digital inputs 3 x dual channel, configurable with filter and monitor functions
Digital outputs 1 x dual channel, configurable
Safety Conformance Level max. SIL 3, PL e category 4
Power supply 24 V DC (SELV/PELV), 3.3 V DC
Environment temperature -30 °C to +68 °C
Dimensions 70 x 40 x 15 mm

IXXAT Safe T100

VScom
 VScom 200E PCIex

Código: 4502

The VScom 200E PCIex is an add-on card for PCI Express, providing two serial ports. These high speed serial ports with their 128 byte long FIFO are best for high speed communication, even in heavy loaded systems. Many unique features reduce the system loa
  • PCI Express x1
  • 2x RS232
  • 16C950 (128 Byte FIFO)
  • 921 kbps
  • PCI Plug and Play
  • Drivers for Windows 2000 to 7/2008R2
  • Extra bracket for Low Profile cases
  Hardware Specifications
Ports 2x RS232 (RxD, TxD, RTS, CTS, DTR, DSR, DCD, RI)
UART 2x 16C950 (128 Byte FIFO)
Address Plug and Play
Interrupts PCI Plug and Play, only one interrupt per card
Speed max. 921 kbps
Bus interface PCI Express x1
Connectors 1x DB25, adapter cable 2 x DB9 male
Low Profile Extra bracket for alternative mounting
Temperature 0°C - 55°C
  High Performance Features
FIFO adjustable FIFO length, 1 up to 128 Bytesseparate adjustable Rx and Tx
Handshake RTS / CTSDTR / DSRXon / Xoffall handshake automatic on Chip
Speed 1 bps up to 921 kbpsunusual Baudrates possibleMultiplication factor for legacy applications
Access high speed access via Memory
UART UART emulation of 8250 up to 16850
  Operating Systems
Windows XP up to 7 VScom high performance serial driver, x86 and x64 Editions
Server 2003 up to 2008 R2 VScom high performance serial driver, x86 and x64 Editions
Linux Kernel 2.6.35 and up: built-in support

VScom 200E PCIex

VScom
 VScom 200Ei-SI PCIex

Código: 4506

The VScom 200Ei-SI PCIex is designed for RS232, RS422/485 industrial communication. It supports 2 independent RS232, RS422 or RS485 ports. Each port can be configured separate.Available modes : RS232, RS422 fullduplexRS485 full duplex (4 wire)RS485 half d
  • PCI Express x 1
  • 2x RS232, RS422/485
  • RS485 ART (Automatic Receive Transmit control)
  • RS485 in 3 operation modes
  • optical isolation, surge protection (also in RS232)
  • Compact board size (half-size)
  • Built-in termination resistors
  • Drivers for Windows 2000 to 7/2008R2
  Hardware
I/O controller 2x 16C950C, each with 128 bytes Tx/Rx FIFO
Connector type Male DB9
  Interface
Bus interface PCI Express x 1
Serial interface RS232, RS422 / 485
No. of ports 2
Signals RS232: TxD,RxD, CTS,RTS isolated and surge protectedRS422: Tx+/-,Rx+/-, RTS+/-,CTS+/-, GNDRS485: Data+/-, GND
RS485 data control ART (Automatic Receive Transmit control)
Built-in termination resistor RS422: 120 OhmRS485: 120 Ohm, DIP enable / disable
  Performance
Speed RS232: up to 921.6KbpsRS422/485: up to 3.6Mbps
Max. no. of ports Unlimited
  Configuration
Parity None, even, odd, space, mark
Data bits 5, 6, 7, 8
Stop bits 1, 1.5, 2
IRQ Assigned by System
I/O address Assigned by System
  Available modes
RS232 full duplex
RS422 full duplex
RS485 4 wire , full duplex
RS485 2 wire, half duplex, with echo
RS485 2 wire, half duplex, without echo
  Power and Environment
Power requirement 430mA max.(+5V)
Operation temp. 0°C - 55°C
Dimension 80mm x 59mm
  Operating Systems supported
Windows XP up to 7 VScom high performance serial driver, x86 and x64 Editions
Server 2003 up to 2008 R2 VScom high performance serial driver, x86 and x64 Editions

VScom 200Ei-SI PCIex

VScom
 VScom 200Ei PCIex

Código: 4505

The VScom 200Ei PCIex is designed for RS232, RS422/485 industrial communication. It supports 2 independent RS232, RS422 or RS485 ports. Each port can be configured separate.Available modes : RS232, RS422 fullduplexRS485 full duplex (4 wire)RS485 half dupl
  • PCI Express x1
  • 2x RS232, RS422/485
  • RS485 ART (Automatic Receive Transmit control)
  • RS485 in 3 operation modes
  • Compact board size (half-size)
  • Built-in termination resistors
  • Drivers for Windows 2000 to 7/2008R2
  Hardware
I/O controller 2x 16C950C, each with 128 bytes Tx/Rx FIFO
Connector type Male DB9
  Interface
Bus interface PCI Express x 1
Serial interface RS232, RS422 / 485
No. of ports 2
Signals RS232 TxD, RxD, CTS, RTS, DTR, DSR, DCD, GNDRS422 Tx+/-, Rx+/-, RTS+/-, CTS+/-, GNDRS485 Data+/-, GND
RS485 data control ART (Automatic Receive Transmit control)
Built-in termination resistor RS422: 120 OhmRS485: 120 Ohm, DIP enable / disable
  Performance
Speed RS232: up to 921.6KbpsRS422/485: up to 3.6Mbps
Max. no. of ports Unlimited
  Configuration
Parity None, even, odd, space, mark
Data bits 5, 6, 7, 8
Stop bits 1, 1.5, 2
IRQ Assigned by System
I/O address Assigned by System
  Available modes
RS232 full duplex
RS422 full duplex
RS485 4 wire , full duplex
RS485 2 wire, half duplex, with echo
RS485 2 wire, half duplex, without echo
  Power and Environment
Power requirement 430mA max.(+5V)
Operation temp. 0°C - 55°C
Dimension 80mm x 59mm
  Operating Systems supported
Windows XP up to 7 VScom high performance serial driver, x86 and x64 Editions
Server 2003 up to 2008 R2 VScom high performance serial driver, x86 and x64 Editions

VScom 200Ei PCIex

VScom
 VScom 800E PCIex

Código: 4504

The VScom 800E PCIex is an add-on card for PCI Express, providing eight serial ports. These high speed serial ports with their 128 byte long FIFO are best for high speed communication, even in heavy loaded systems. Many unique features reduce the system l
  • PCI Express x1
  • 8x RS232
  • 16C950 (128 Byte FIFO)
  • 921 kbps
  • PCI Plug and Play
  • Drivers for Windows 2000 to 7/2008R2
  Hardware Specifications
Ports 8x RS232 (RxD, TxD, RTS, CTS, DTR, DSR, DCD, RI)
UART 8x 16C950 (128 Byte FIFO)
Address Plug and Play
Interrupts PCI Plug and Play, only one interrupt per card
Speed max. 921 kbps
Bus interface PCI Express x1
Connectors 1x DB62, optional adapter cable or box
Temperature 0°C - 55°C
  High Performance Features
FIFO adjustable FIFO length, 1 up to 128 Bytesseparate adjustable Rx and Tx
Handshake RTS / CTSDTR / DSRXon / Xoffall handshake automatic on Chip
Speed 1 bps up to 921 kbpsunusual Baudrates possibleMultiplication factor for legacy applications
Access high speed access via Memory
UART UART emulation of 8250 up to 16850
  Operating Systems
Windows XP up to 7 VScom high performance serial driver, x86 and x64 Editions
Server 2003 up to 2008 R2 VScom high performance serial driver, x86 and x64 Editions
Linux Kernel 2.6.35 and up: built-in support

VScom 800E PCIex

VScom
 VScom 400E PCIex

Código: 4503

The VScom 400E PCIex is an add-on card for PCI Express, providing four serial ports. These high speed serial ports with their 128 byte long FIFO are best for high speed communication, even in heavy loaded systems. Many unique features reduce the system lo
  • PCI Express x1
  • 4x RS232
  • 16C950 (128 Byte FIFO)
  • 921 kbps
  • PCI Plug and Play
  • Drivers for Windows 2000 to 7/2008R2
  • Extra bracket for Low Profile cases
  Hardware Specifications
Ports 4x RS232 (RxD, TxD, RTS, CTS, DTR, DSR, DCD, RI)
UART 4x 16C950 (128 Byte FIFO)
Address Plug and Play
Interrupts PCI Plug and Play, only one interrupt per card
Speed max. 921 kbps
Bus interface PCI Express x1
Connectors 1x DB44, adapter cable 4 x DB9 male
Low Profile Extra bracket for alternative mounting
Temperature 0°C - 55°C
  High Performance Features
FIFO adjustable FIFO length, 1 up to 128 Bytesseparate adjustable Rx and Tx
Handshake RTS / CTSDTR / DSRXon / Xoffall handshake automatic on Chip
Speed 1 bps up to 921 kbpsunusual Baudrates possibleMultiplication factor for legacy applications
Access high speed access via Memory
UART UART emulation of 8250 up to 16850
  Operating Systems
Windows XP up to 7 VScom high performance serial driver, x86 and x64 Editions
Server 2003 up to 2008 R2 VScom high performance serial driver, x86 and x64 Editions
Linux Kernel 2.6.35 and up: built-in support

VScom 400E PCIex

Actualmente estamos trabajando en mostrarte los mejores resultados, si no encuentras el producto que buscas contacta con nosotros a través de info@er-soft.com o al número Tel. +34 916-408-408
Bienvenido a ER-Soft.
ER-Soft con la ley orgánica de protección de datos
Política de cookies.
Utilizamos cookies propias y de terceros para mejorar nuestros servicios y mostrarle publicidad relacionada con sus preferencias mediante el análisis de sus hábitos de navegación.
Si continúa navegando, consideramos que acepta su uso.
Más información pulsando aquí
X

¿Necesitas ayuda? Click

ayuda ER-Soft
X
Consulta a ER-Soft. *



*



* *Campos obligatorios.




*Al enviar el formulario consideramos que esta de acuerdo, con nuestra política de datos. Ver política de datos
X
